Description
Multiple System Modes: Idle Mode: Power Saving mode while remote is not in use Active Mode: Device switches to Active Mode after a button is pressed. Stays in Active Mode for 5 seconds Low Battery Mode: Activated when the battery has dropped below 2.4V Configuration Mode: To setup and configure the remote Indication Keys (On/Off): Low Battery indicator: Power OFF LED blinks every one second while in active mode Battery Charging indicator: Power ON LED blinks every one second while in active mode Full Charge indicator: Both Power ON and OFF LEDs blink every one second while in active mode Configuration Mode indicator: Both Power ON and OFF LEDs are steadily illuminated 7 Device Keys: The selected Device Key LED will remain illuminated to indicate which device is selected
- 48 Programmable Hard Buttons:& For IR and/or RF ZigBee commands programmable via USB on PC or Mac with Compass Navigator™ PC Software
- Programming Support:& Unlimited macro and variable actions
- ZigBee Signal Transmission:& Up to 100’ through walls, doors and floors
- Device Control:& Up to 10 devices with line-of-sight IR control or RF Wireless 2.4 GHz ZigBee control
- Backlight:& Motion detected automatic backlighting. The backlight will turn on when movement is detected and will stay on for five seconds after movement has stopped
- USB:& Recharging and Programming
-
Multiple System Modes:
- Idle Mode:& Power Saving mode while remote is not in use
- Active Mode:& Device switches to Active Mode after a button is pressed. Stays in Active Mode for 5 seconds
- Low Battery Mode:& Activated when the battery has dropped below 2.4V
- Configuration Mode:& To setup and configure the remote
-
Indication Keys (On/Off):
- Low Battery indicator:& Power OFF LED blinks every one second while in active mode
- Battery Charging indicator:& Power ON LED blinks every one second while in active mode
- Full Charge indicator:& Both Power ON and OFF LEDs blink every one second while in active mode
- Configuration Mode indicator:& Both Power ON and OFF LEDs are steadily illuminated
- 7 Device Keys:& The selected Device Key LED will remain illuminated to indicate which device is selected
