Description
- Multipurpose Tripod head made for compact system cameras
- Easy locking and full pan and tilt movement
- Strong enough to easily support up to 4kg
- Features standard 9.5mm bottom attachment for versatility
- ¼” standard camera screw
DESCRIPTION
For all amateur photographers looking for a small and reliable head to perfectly match their compact camera or to support the ideal accessory to enrich the shot the MH492-BH is the head for taking it to the next level. Versatile, user-friendly, and made to last, this multi-purpose photographic head is made of highly resistant, lightweight aluminium so it is both portable and strong and it features a single ergonomic knob that controls both pan and tilt movements to be ready and fast in framing and shooting.
Complete with universal attachments such as a 6.35mm platform attachment and a 9.5mm female attachment at the base of the ball, you’ll be ready for anything. Compatible and practical, the MH492-BH simplifies any shoot.
SPECIFICATIONS:
|
Weight |
140 g |
|
Safety Payload Weight |
4 kg |
|
Material |
Aluminum |
|
Head Type |
Ball Head |
|
Top Attachment |
1/4″ screw |
|
Base Diameter |
35 mm |
|
Plate Type |
fixed - with 1/4″ screw |
|
Friction Control |
No |
|
Front Tilt |
-90° / +40° |
|
Lateral Tilt |
-90° / +40° |
|
Panoramic Rotation |
360 |
|
Base Type |
22 mm |
|
Ball Locking |
Yes |
|
Color |
Black |
|
Easy Link |
No |
|
Independent Pan Lock |
no |
|
Independent Tilt Lock |
no |
|
Maximum Working Temperature |
70 |
|
Minimum Working Temperature |
-30 |
|
Pan Bar Included |
No |
|
Pan Drag |
NONE |
|
Quick Release |
No |
|
Working Height |
6.5 cm |
|
Tilt Drag |
NONE |
